Product Overview
LED Indoor Electronic Ribbon Light Plug-In Drivers, 48W - ULR-IN-PIDR-48W
Technical Specs:
:: Input voltage: 100~240VAC, 50/60Hz
:: AC Input Current: Max 0.5A
:: Output power: 48W
:: Output DC Voltage: 24VDC
:: Min Load: 0.00A
:: Rated Load: 2A
:: Line Regulation: ± 1%
:: Load Regulation: ± 5%
:: Efficiency: 82% Min
:: Turn on delay time: 3Sec Max. at 115VAC & Max Load
:: Rise time: 40mS Min. at 115VAC & Max Load
:: Hold up time: 5mS Min. at 115VAC & Max Load
:: Male 24V connector included
:: Operating Temperature: 32°F to 104°F
:: Protection Function: Short Circuit Test, Over current protection, Over Voltage Protection
:: Relative Humidity: 5% to 90% RH, 72Hrs, Full Load , Normal operating.
:: Ripple and Noise: 240mV p-p
:: EN55022
:: AC power cord can be cut for hardwiring. Ensure proper installation according to local electrical codes and standards.
:: DIELECTRIC STRENGTH Hi-Pot: Primary to secondary: 3000Vac10mA/3S for type test.
:: Insulation resistance: Primary to secondary:10MΩ min at 500V DC
